SKU: CP0000004481 SKU e prodhuesit: 0544-001 Kategori: Audio / Video, Cameras, Video Surveillance, Environment Monitoring, Others Brand: Axis Communication

Axis pan/tilt/zoom cameras

Intelligent direct drive PTZ dome with HDTV 720p

Intelligent Direct Drive PTZ camera with HDTV 720p, day/night and 18x zoom, designed for mounting on a wall or building. No extra bracket are needed, build in junction box. Audio In/Out, full size SD card, 24 V DC, 4 configurable I/Os and Ethernet connector with PoE. Repaintable sunshield covering the entire unit. Power supply not included.

Key features :

Direct drive pan-tilt-zoom mechanism with no belts or gears for low maintenance and longlivity
270° wide angle coverage for effective monitoring of large sites
IP66 casing with sunshield has sloped design to prevent vandalism and can withstand harsh weather and low temperatures for outdoor use. The casing can also be painted to blend in with surrounding for discreet surveillance
30 fps HD 720p video provides high quality surveillance at a frame rate sufficient for most CCTV applications
18x optical zoom enables detailed, close-up viewing of specific areas for event analysis and identification
Automatic true day/night provides a 24/7 security solution, producing monochrome images at night for constant high quality monitoring
Two-way audio support enables a speaker and microphone to be added for verbal interaction through the camera to give instructions or warnings
Axis Advanced Gatekeeper automatically moves camera to a preset position when motion is detected in a user-defined area for fast, efficient surveillance
Hidden junction box with easy access to the camera’s interface including audio connections, four alarm in/outputs, RJ-45 connection with PoE and a 24V ac power input
Motion and audio detection can trigger alarms to alert the user and record to SD card
H.264 and Motion JPEG compression gives the user a code choice and flexibility on bandwidth and storage use
PoE support makes installation of the P5414-E quick and easy with only one cable
SD storage provides a cost-effective alternative to PCs and servers for data storage

Typical applications

The Axis P5414-E network camera is suitable for outdoor surveillance of large areas that require efficient, high quality monitoring at all times, with focus on certain areas needed at times. Suitable applications include large outdoor car parks, public building grounds, university campuses and city surveillance.

Datasheet

Përshkrimi

Key technical features of the Axis P5414-E

Camera
Environment:	outdoor
Type:	PTZ dome
Sensor:	1/2.9 progressive scan RGB CMOS
Lens:	f=4.7~84.6 mm, F1.6~2.8, autofocus, horizontal angle of view: 59°~4°
Optical zoom:	18x
Power:	Power over Ethernet Plus (PoE+) IEEE 802.3at type 2 class 4
Memory:	256 MB RAM, 128 MB Flash
Video
Resolution:	1280×720 (HDTV 720p) to 240×135
Compression:	H.264 main and baseline profiles (MPEG-4 Part 10/AVC), Motion JPEG
Frame-rate:	H.264: up to 25/30 fps (50/60 Hz) in all resolutions, Motion JPEG: Up to 25/30 fps (50/60 Hz) in all resolutions
Bandwidth control:	multiple, individually configurable streams in H.264 and Motion JPEG, controllable frame rate and bandwidth VBR/CBR H.264
Day/night:	automatically removed infrared cut-filter
Minimum illumination:	colour: 0.4 lux at 30 IRE F1.6, B/W: 0.04 lux at 30 IRE F1.6
PTZ	pan: ° 135°, 0.2~350°/s, tilt: 0°~ 90°, 0.2~350°/s, 18x optical zoom and 12x digital zoom, total 216x zoom, 100 preset positions, limited guard tour, control queue, focus window, on-screen directional indicator
Video overlay:	text and image
Imaging:	compression, colour, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behaviour at low light
Viewing, detection & recording
Privacy masking:	20 individual 3D privacy masks
Number of users:	not given
External alarm inputs and outputs	terminal blocks forDC input, 4 configurable alarm inputs/outputs, mic in/line in, line out
Alarm detection:	video motion detection, audio detection, Advanced Gatekeeper, AXIS Camera Application Platform enabling installation of additional applications
Alarm action:	file upload: FTP, HTTP, network share and email, notification: email, HTTP and TCP, external output, PTZ preset, guard tour, play audio clip, video and audio recording to edge storage, day/night mode, pre- and post-alarm video buffering
Pre-/post-alarm buffer:	yes
On-camera recording:	SD/SDHC/SDXC slot supporting memory card up to 64 GB (card not included), support for recording to network share (network-attached storage or file server)
Recording software supported:	Axis Camera Station
Connections
Power:	Power over Ethernet Plus (PoE+) IEEE 802.3at type 2 class 4
Network:	RJ45 for 10BASE-T/100BASE-TX PoE
Alarm I/O:	4 configurable alarm inputs/outputs
Audio:	external microphone or line input, and line output
Other:	terminal blocks for DC input
Other
Dimensions:	without sunshield: D224mm x H265mm x W169mm, with sunshield: D239mm x H279mm x W193mm
Weight:	3.5kg (net)
Warranty:	3 year
Mounting methods:	wall, corner (with additional adapter)
Operating temperatures:	-20°C to 50°C (-4°F to 122°F)
Power consumption:	max. 30
Dynamic DNS:	yes
Protocols supported:	IPv4/v6, HTTP, HTTPSb, SSL/TLSb, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
QoS:	yes
Security:	password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb, network access control, digest authentication, user access log
ONVIF compliant:	yes, profile S

Më shumë informacion

Compression Type	MULTIPLE COMPRESSION TYPES
Signal Process	IP
PoE	Yes
Zoom (Optical/Digital)	18/12
Max. frames per second	25/30
Day and night mode	Not given
Max. video resolution	1280x720
Environment	Outdoor
