AXIS M3104-L Network Camera

Axis fixed dome cameras

Discreet HDTV 720p video surveillance with built-in IR illumination

Day/night, compact mini dome with flat-faced design for indoor use. Built-in IR illumination and WDR – Forensic Capture. Fixed lens. Multiple, individually configurable H.264 and Motion JPEG streams; max HDTV 720p resolution at 30 fps. Axis’ Zipstream technology for reduced bandwidth and storage needs.  Memory card slot for optional local video storage. Video motion detection and active tampering alarm. Power over Ethernet. Midspan not included.

Key features:

• Capable of delivering up to HD 720p resolution at 25 fps, providing high quality CCTV footage
• True day/night functionality with integrated IR-cut filter provides round-the-clock surveillance
• Power efficient, built-in infrared LED provides up to 15m of night-vision
• Innovative flat-faced design reduces light reflections to improve images captured in low light
• WDR – Forensic Capture optimises the image and ensures all details are visible in high contrast scenes
• Axis Corridor Format optimises viewing in narrow scenes and maximises the area of interest
• Simple video management for up to 16 cameras using the free Axis Companion application
• Configurable, camera-based video motion detection and tampering alarms help to enhance security monitoring
• Recordings can be written to the on-board MicroSD card (not included) – helpful in a stand alone set up
• Support for power and network connectivity through PoE enables simple installation
• 3-axis mount design enables easy manual adjustment of the lens for quick set up
• Axis’ Zipstream technology optimises the video stream in real-time, lowering bandwidth and storage levels by up to 50%

Typical applications

The Axis M3104-L is a feature packed mini-dome delivering high-quality HD 720p resolution at an attractive price. It’s an ideal choice for users that require simple and reliable CCTV monitoring in locations such as independent retail stores, waiting areas and entrance ways.
