Name: AXIS T93F10 Outdoor Housing
Availability: OutOfStock

SKU: CP0000004583 SKU e prodhuesit: 5900-271 Brand: Axis Communication

HOUSINGS & CABINETS

AXIS T93F10 supports IP66 and NEMA 4X rating against the ingress of dust and water, and IK10 rating for protection against impact and vandal acts. The installer-friendly, lightweight plastic casing protects from corrosion. All cables are protected inside the wall mount to enhance vandal protection and remove the risk of solar degradation. Arctic Temperature Control ensures that the camera can start up even at -40 °C (-40 °F) following a power failure. AXIS T93F10 features a terminal connector for AC/DC power. A slot is dedicated for an optional intrusion alarm switch. It comes with a wall mount and an integrated sun cap.

KEY FEATURES

AC/DC power connection.
Protection against water, dust and corrosion.
Impact resistant.
Lightweight.
Included wall mount.

Datasheet

Përshkrimi

Features to protect what you value

AXIS T93F Housing Series has IP66 and NEMA 4X protection rating against the ingress of dust, windblown dust, rain, high pressure water jets from any direction, hose-directed water, and damage from external ice formation. IK10-rated for protection against impact and vandal acts. In addition, the cables are vandal protected and it is prepared to accommodate an optional alarm switch that triggers at vandal attempts.

Ease of installation

AXIS T93F Series is out-of-the-box ready for installation outdoors. AXIS T94Q01A Wall Mount is included. For installations involving protective pipes, AXIS T94R01P Conduit Back Box (optional accessory) should be used. Threaded holes underneath the housing simplify installation of Axis Illuminators.

Extra room for more

AXIS T93F Housing Series offers an empty space behind the camera, useful if a larger lens is needed for the camera or to place other devices. See the dimensions drawing for more information.

TECHNICAL SPECIFICATIONS

Supported products:

AXIS P13 Series.
AXIS Q16 Series.
AXIS M1124/M1125.

Power:

20-24 V AC, max 29 VA (Power supply not included).
12-28 V DC, max 25 W.

Operating conditions: AXIS P1353/P1354/P1355/P1357 and AXIS Q1604/Q1614: -40 ºC to 50 ºC (-40 ºF to 122 ºF) AXIS P1365 and AXIS Q1615/Q1635: -40 ºC to 55 ºC (-40 ºF to 131 ºF) AXIS M1124/M1125: -40 °C to 55 °C (-40 ºF to 131 ºF).
Approvals: EN 50581, IEC/EN/UL 60950-1, IEC/EN/UL 60950-22, IEC/EN 60529 IP66, IEC/EN 60529 IP67, NEMA 250 Type 4X, IEC 60721-4-3 Class 4M4, IEC 60068-2-6, IEC 60068-2-27, IEC/EN 62262 IK10 EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, KCC KN22 Class B, KN24, EN 62236-4 EN 55022 Class A, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 22 Class A Weight 1.2 kg (2.6 lb) Dimensions 155 x 120 x 400 mm (6.1 x 4.8 x 15.7 in).
Included accessories: AXIS T94Q01A Wall Mount Gaskets C M20 Internal power cable 2 pin plug connector for AC/DC power cable Screw bit T30, Installation Guide Required tool: Torx® T20 screw driver (not included) Optional accessories AXIS T91A47 Pole Mount AXIS Sunshield A AXIS Corridor Format Bracket A/B AXIS Bird Control Spike.
Optional accessories:

AXIS T91A47 Pole Mount.
AXIS Sunshield A.
AXIS Corridor Format Bracket A/B.
AXIS Bird Control Spike.

Më shumë informacion

Connectors	Terminal connector for AC/DC power
Environment	Indoor/outdoor
Color	White NCS S 1002-B
Weight	1.2 kg (2.6 lb)
Dimensions	155 x 120 x 400 mm (6.1 x 4.8 x 15.7 in)
