Camera
|
| Environment: |
Indoors |
| Type: |
Covert IP camera |
| Sensor: |
1/4″ progressive scan CMOS sensor |
| Lens: |
Fixed 3.7mm (F2.5) with 57° horizontal viewing angle |
| Power: |
8-28V DC or IEEE802.3af Power over Ethernet (class 2) |
| Memory: |
256MB RAM and 128MB Flash |
| Compatibility: |
Compatible browsers include Internet Explorer, Firefox, Safari and Chrome on Windows, Mac and Linux-based computers |
|
Video
|
| Resolution: |
Various resolutions between 1280×720 and 320×180 |
| Compression: |
H.264 and MJPEG |
| Frame-rate: |
Up to 25fps in all resolutions and compression formats |
| Bandwidth control: |
Constant and variable bit-rate H.264 transmission. Multiple JPEG compression levels |
| Day/night: |
Day only |
| Minimum illumination: |
1.2 lux |
| Video overlay: |
Text and image overlay |
| Imaging: |
Adjustable compression, colour, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behaviour at low light, rotation and mirroring of images |
|
Viewing, detection & recording
|
| Multi-camera viewing: |
Yes, using Axis Companion software (free download) |
| Privacy masking: |
Yes |
| Alarm detection: |
Intelligent video, external input and loss of video |
| Intelligent video: |
Video motion detection, active tampering alarm and Axis Camera Application Platform |
| External alarm inputs and outputs: |
1x alarm input and 1x relay output |
| Alarm notifications: |
File upload via FTP, HTTP, network share and email, Notification via email, HTTP and TCP, external relay output, and recording to edge storage |
| Recording triggers: |
Manual and alarm |
| On-camera recording: |
SD/SDHC memory card slot |
| Recording software supported: |
Axis Camera Station, Axis Companion software |
|
Compatible recording platforms (not included)
|
| Software: |
Axis Camera Station, Milestone XProtect, SecuritySpy (for Mac OSX) |
|
Connections
|
| Power: |
Terminal block connectors for 8-28V DC |
| Network: |
10/100Mbps RJ-45 Ethernet connection with PoE support |
| Alarm I/O: |
Terminal block connectors for 1x alarm input and 1x relay output |
|
Other
|
| Dimensions: |
Camera module: ø20mm x 42mm. Main unit: 31mm x 76mm x 104mm |
| Weight: |
Main unit: 109g. Sensor unit: 238g |
| Colour: |
Camera: Black. Main unit: White |
| Warranty: |
3-Year manufacturer’s warranty |
| Mounting methods: |
Designed to be recessed into walls (brackets included) |
| Operating temperatures: |
−20 to 50°C |
| Power consumption: |
6.49W max |
| Dynamic DNS: |
Yes, using Axiscam.net |
| Protocols supported: |
IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP and SOCKS |
| QoS: |
Yes |
| Security: |
Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication and user access log |
| System integration: |
VAPIX API available from Axis |
| ONVIF compliant: |
Yes |
