Name: AXIS P3365-VE Network Camera
Availability: OutOfStock

SKU: CP0000004416 SKU e prodhuesit: 0587-001 Kategori: Audio / Video, Cameras, Video Surveillance, Environment Monitoring Brand: Axis Communication

Axis fixed dome cameras

Wide-angle and vandal-resistant with remote zoom and focus

Day/night fixed dome with vandal-resistant, IP66-rated outdoor casing. Varifocal 3-9 mm
P-iris lens, remote focus and zoom. Multiple, individually configurable H.264 and Motion JPEG streams; max full HDTV 1080p / 2MP resolution at 30 fps. WDR. Video motion detection and active tampering alarm. Two-way audio and audio detection. I/O for alarm/event handling, SD/SDHC memory card slot for optional local video storage. Operation in -40°C to +55°C powered by standard Power over Ethernet. Midspan not included. Includes smoked and clear transparent covers, weather shield against sun, rain or snow, and 5m Ethernet cable with mounted gasket.

Key features:

Full frame rate HD 1080p video capture (30 fps) provides smooth surveillance footage ideal for most general CCTV applications
100° view provides wide area coverage
Outdoor-ready casing is IP66 and IK10-rated, providing protection against rain, dust and impact
Automatically removable IR-cut filter provides the camera with true day/night functionality for 24 hour image capture
P-iris lens improves contrast, depth of field, clarity and resolution for optimum image capture
Focus and zoom can be adjusted remotely using the network instead of manually for easier installation
Wide dynamic range (WDR) improves image capture in challenging lighting conditions, enabling clear identification
Full view and cropped areas can be viewed simultaneously with multi-view streaming
Camera can facilitate audio recording and verbal interaction when a speaker and microphone are connected (not included), providing two-way audio
I/O ports enable connection of external devices
Video, tamper and audio detection provide reliable and accurate security monitoring, alerting users to an event via a variety of methods
Dual codec provides compression flexibility
Digital PTZ enables closer viewing of regions of interest
PoE lowers the cost of installation
SD card slot provides cost-effective edge storage (SD card not included)

Typical applications

An outdoor-ready casing, full HD 1080p and true day/night functionality make the Axis P3365-VE dome network camera ideal for general external surveillance applications that require round-the-clock high quality, smooth video capture. Typical examples include car parks, retail stores, offices and railway stations.

Datasheet

Përshkrimi

Key technical features of the Axis P3365-VE

Camera
Environment:	outdoor (IP66), vandal-resistant (IK10)
Type:	fixed dome
Sensor:	progressive scan RGB CMOS 1/2.8
Lens:	varifocal, remote focus and zoom, P-iris control, IR corrected, megapixel resolution, 3~9 mm, 100°~35° view, F1.3
Power:	Power over Ethernet IEEE 802.3af/802.3at type 1, class 3, max. 8.6 W
Memory:	256 MB RAM, 128 MB Flash
Audio:	two-way, AAC LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, configurable bit rate, external microphone input or line input, line output
Video
Resolution:	1920×1080 (2 MP) to 160×90
Compression:	H.264 main and baseline profiles (MPEG-4 Part 10/AVC), Motion JPEG
Frame-rate:	25/30 fps with power line frequency 50/60 Hz
Bandwidth control:	multiple, individually configurable streams in H.264 and Motion JPEG controllable frame rate and bandwidth, VBR/CBR H.264
Day/night:	automatically removable infrared cut-filter
Minimum illumination:	colour: 0.2 lux, F1.2, B/W: 0.04 lux, F1.3
Digital zoom/PTZ	digital PTZ
Overlay:	text and image
Imaging:	compression, colour, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behaviour at low light, wide dynamic range – dynamic contrast, rotation: 0°, 90°, 180°, 270° including Corridor Format, mirroring of images
Viewing, detection & recording
Privacy masking:	yes
Number of users:	not given
Alarm detection:	video motion detection, active tampering alarm, AXIS Camera Application Platform enabling installation of additional applications, audio detection, external output, edge storage events
Alarm action:	file upload: FTP, HTTP, email, notification: email, HTTP, TCP, video recording to edge storage, pre- and post-alarm video buffering, status LED activation, external output activation, video and audio recording to edge storage, external output activation, audio recording to edge storage, play audio clip
Pre-/post-alarm buffer:	yes
On-camera recording:	SD/SDHC/SDXC slot supporting memory cards with up to 64 GB of storage (not included), support for recording to dedicated network-attached storage (NAS)
Recording software supported:	Axis Camera Station
Connections
Power:	Power over Ethernet IEEE 802.3af/802.3at type 1, class 3
Network:	RJ45 10BASE-T/100BASE-TX PoE
SD card slot:	SD card
Audio:	external microphone input or line input, line output
Other:	terminal block for 1 alarm input and 1 output, 3.5 mm mic/line in, 3.5 mm line out
Other
Dimensions:	178mm (D) x 123mm (H)
Weight:	1.7 kg with weather shield
Casing:	polycarbonate transparent dome, aluminium inner camera module with encapsulated electronics, IP66- and NEMA 4X-rated, IK10 impact-resistant casing with aluminium base and dehumidifying membrane, colour: white NCS S 1002-B
Warranty:	3 years
Mounting methods:	wall
Operating temperatures:	-40°C to 55°C
Power consumption:	max. 8.6W
Dynamic DNS:	yes
Protocols supported:	IPv4/v6, HTTP, HTTPSa, SSL/TLSa, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP”, SNMP, v1/v2c/v3(MIB-II), DNS,,DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
QoS:	yes
Security:	password protection, IP address filtering, HTTPS encryption, digest authentication, user access log
ONVIF compliant:	yes, profile S

Më shumë informacion

Environment	OUTDOOR
Lens Type	VARI-FOCAL
Compression Type	H.264
Max. video resolution	1920x1080
Day and night	YES
Signal Process	IP
Position Type	FIXED
PoE	YES
Max. frames per second	25/30
