cnPilot™ R200P

22,570L

(me TVSH)

SKU: CP0000004107 SKU e prodhuesit: C000000L027A Kategori: , , , Brand:

cnPilot™ R200P, 802.11n single band 2×2:2 300Mbps WLAN Router with ATA  2xFXS port and PoE OUT, 5 x 10/100 Ethernet port, 1 x USB 2.0 port, DynDNS/DNS SRV, PPTP/L2TP VPN, NAT, DHCP Client & Server, IP Conflict detection, Router mode, Bridge mode, Security, Client Isolation, WMM, MAC Filter, WDS, WPS

Key Features:

  • Supports cnMaestro (Cambiums cloud management application)
  • Out-of-the box zero touch onboarding
  • Stateful alarms and dashboard views
  • Multiple management options available including cloud-based, TR-069, SNMP and an enriched set of RESTful interfaces
  • Multiple SSIDs and Service Provider (community) SSID’s
  • One-click functionality reveals the health of all network nodes related to the problem area
  • Troubleshoot end user client connectivity on any WLAN from a single console
  • No truck roll required to debug wired or wireless connectivity configurations

Datasheet

Out of stock

Përshkrimi

Product code  cnPilotR200P
WLAN Routers  802.11n Single band 2.4 GHz
ATA – for Voice  Yes
Cambium PoE out  Yes
Telephone Interfaces  2 FXS ports, RJ11
WAN  1 x 10/100Base T.RJ45
LAN  4 x 10/100BaseT, RJ45
USB  1 USB 2.0 Host Port for shared printer or storage
WiFi  2×2 Single band 11n 2.4 GHz
SSIDs 4 Per Radio  4
Wireless Interfaces
Protocol  802.11 b/g/n
Security  WEP, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-  PSK (TKIP), WPA2-PSK (AES), Mixed mode
Others  AP isolation, MBSSID AP isolation, WMM, MAC  Filter, WDS, WPS
Call Features
IP Signaling  SIP V2 (RFC3261/3262/ 3263/3264)
Voice Codec  G.711 (A-law, µ-law), G.722, G.723, G.729
Fax Over IP  Real Time FAX over IP via T.38
AC/DC ADPATOR  AC INPUT: 100 ~240V, 50-60 Hz DC OUTPUT:  12V, 2A
Operation Temp  +5°C to +45°C 5°C to +45°C
Storage Temp  25°C to +85°C
Relative Humidity  10%~90% No Condensing
Dimensions  180 x 110 x 30 mm
Weight  0.75Kg
EMC  FCC part 15B Class B, ETSI EN 301 489-1, ETSI EN  301 489-17, EN61000-6-1, EN61000-6-3, CE, RoHS
SAFETY  IEC 60950-1, UL 60950-1, EN 60950-1,



Më shumë informacion

WLAN Routers 802.11n Single band 2.4 GHz
WAN 1 x 10/100 RJ45
LAN 4 x 10/100BaseT, RJ45
Wi F x2 Single band 11n 2.4 GHz
