SuperServer 1028TP-DC1TR

506,813L

(me TVSH)

SKU: CP0000003974 SKU e prodhuesit: N/A Kategori: , , , Brand:

Key Features

  •  4x 2.5 Hot-swap SAS3 drive bays
  •  Intel® X540 Dual port 10GBase-T LAN
  • LSI 3108 SAS3 controller; RAID 0, 1, 10, 5, 6
  • 1x PCI-E 3.0 x16 Low-profile slot and 1x 0 slot
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
  • 1000W Redundant Power Supplies Titanium Level (96%)
  • Up to 1TB ECC LRDIMM, 512GB ECC RDIMM, up to 2133MHz; 16x DIMM sockets
  • Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v3 family; QPI up to 9.6GT/s

Datasheet

Out of stock

Përshkrimi

Main Specifications
Built-in Devices Super X10DRT-PT
Device Type SuperServer
Dimensions (WxDxH) Width 17.2″ (437mm) x Height 1.7″ (43mm) x Depth 28.75″ (730mm)
Enclosure Color Black
Form Factor 1U Rackmount – CSE-809H-R1K05
Processor
Cache Up to 18 Cores / Up to 45MB Cache
Compatible Processors Intel® Xeon® processor E5-2600 v3 family (up to 145W TDP)
Compatible Socket Dual Socket R3 (LGA 2011)
QPI QPI up to 9.6 GT/s
System Memory
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB – LRDIMM: 64GB, 32GB
Error Detection Corrects single-bit errors
Memory Capacity 16x 288-pin DDR4 DIMM slots, Up to 1TB ECC LRDIMM, 512GB ECC RDIMM
Memory Type 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
Memory Voltage 1.2 V



Më shumë informacion

BIOS Type 128Mb SPI Flash EEPROM with AMI BIOS
Memory Capacity 16x 288-pin DDR4 DIMM slots, Up to 1TB ECC LRDIMM, 512GB ECC RDIMM
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB - LRDIMM: 64GB, 32GB
Cache Up to 18 Cores / Up to 45MB Cache
Dimensions (WxDxH) Width 17.2" (437mm) x Height 1.7" (43mm) x Depth 28.75" (730mm)
Server version Twin PRO, 2 x hot plugable nodes in 1U
Applications * Mission-critical applications * High Availability Storage Appliance Platform
Power supply redundant 80+ Titanium
