- 7.1 HD Audio
- Whisper Quiet Workstation
- Intel® i210 Dual port GbE LAN
- 900W Multi-output Power Supply Gold Level Certified
- Up to 2TB ECC 3DS LRDIMM, up to DDR4-2400MHz; 16x DIMM slots
- 4x 3.5 HDD bays (internal), 2x 5.25 drive bays, and 1x 3.5 internal fixed drive bay
- 3x PCI-E 3.0 x16, 2x PCI-E 3.0 x8, 1x PCI-E 2.0 x4 (in x8) slot supports Thunderbolt 2.0 AIC
- Dual socket R3 (LGA 2011) supports Intel Xeon processor E5-2600 v4/ v3 family; QPI up to 9.6GT/s
159,150L
(me TVSH)
Out of stock
Përshkrimi
• Whisper Quiet Workstation
Global SKU
| Product SKUs | |
| SuperWorkstation | SYS-7038A-I (Black) |
| Motherboard | |
| Motherboard | Super X10DAi |
| Processor/Cache | |
| CPU |
|
| Cores / Cache | Up to 18 Cores / Up to 45MB Cache |
| System Bus | QPI up to 9.6 GT/s |
| Note | * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. |
| System Memory | |
| Memory Capacity |
|
| Memory Type | 2133/1866/1600/1333MHz ECC DDR4 SDRAM 72-bit, 288-pin (RDIMM/LRDIMM) / 284-pin gold-plated DIMMs |
| DIMM Sizes | RDIMM: 32GB, 16GB, 8GB, 4GB |
| Memory Voltage | 1.2 V |
| Error Detection |
|
| On-Board Devices | |
| Chipset | Intel® C612 chipset |
| SATA | SATA3 (6Gbps); RAID 0, 1, 5, 10 |
| Network Controllers |
|
| Audio | RealTek ALC888 7.1 High Definition Audio with S/PDIF header |
| Super I/O | Nuvoton W83627 |
| Input / Output | |
| SATA | 10x SATA3 (6Gbps) ports |
| LAN | 2x RJ45 Gigabit Ethernet LAN ports |
| USB |
|
| Audio | 7.1 HD Audio with optical S/PDIF |
| DOM | 2x DOM (Disk on Module) power connectors |
| TPM | 1x TPM 1.2 20-pin Header |
| Expansion Slots | |
| PCI-Express |
|
Më shumë informacion
| Motherboard | Super X10DAi |
|---|---|
| System Bus | QPI up to 9.6 GT/s |
| DIMM Sizes | RDIMM: 32GB, 16GB, 8GB, 4GB |
| SATA | SATA3 (6Gbps); RAID 0, 1, 5, 10 |
