Hardened MSA Compliant 1000Base Fiber Channel SFP 1000Base-LX 1550nm TX/1310nm RX (Simplex LC) [10 km/6.2 mi.]

Ask us about this product

Shiko listën

The product is already in quote request list!
Vlereso këte produkt
Me porosi

48,924L

(me TVSH)

SKU: CP0000004834 SKU e prodhuesit: TN-SFP-LXB12T Kategori: IT Infrastructure Brand: Transition Networks

1000Base-LX 1550nm TX/1310nm RX single mode (Simplex LC) with DMI [10 km/6.2 mi.] Link Budget: 11.0 dB.

Per Cisco Systems’ literature, the Cisco switches with SFP slots do not accept modules other than Cisco’s own SFPs. The Cisco switch identifies the manufacturer ID along with the part number and blocks operations to this port for non-Cisco interfaces.

KEY FEATURES

Hot-Pluggable SFP Footprint Optical Transceiver.
Digital Diagnostic Function.
Class 1 Laser International Safety Standard IEC-60825 Compliant.
Compatible with SFP Multi-Sourcing Agreement (MSA).

Out of stock

Përshkrimi

Standards: IEEE 802.3z.

Dimensions

Width: 0.52” [13 mm].
Depth: 2.18” [55 mm].

Environment: Operating: -40°C to 85°C.

Compliance: IEC-60825, FDA 21, CFR 1040.10 and 1040.11.

Më shumë informacion

Power Consumption	0.66 Watts
Power Input	3.3V
Warranty	Lifetime
Height	0.33" [8 mm]
