Name: SYS-5018R-M
Price: 149610 ALL
Availability: OutOfStock

Global SKU

Product SKUs
SYS-5018R-M	SuperServer 5018R-M (Black)
Motherboard
Motherboard	Super X10SRi-F
Processor
CPU	Intel® Xeon® processor E5-2600/1600 v3 family (up to 145W TDP **) Single Socket R3 (LGA 2011)
Core / Cache	Up to 18 Cores / Up to 45MB Cache
Note	** Motherboard supports this maximum TDP. Please verify your system can thermally support
System Memory
Memory Capacity	8x 288-pin DDR4 DIMM slots Up to 512GB DDR4 ECC LRDIMM Up to 256GB DDR4 ECC RDIMM
Memory Type	2133/1866/1600/1333MHz ECC DDR4 SDRAM 72-bit, 288-pin (RDIMM/LRDIMM) / 284-pin gold-plated DIMMs
DIMM Sizes	RDIMM: 32GB, 16GB, 8GB, 4GB
Memory Voltage	1.2 V
Error Detection	Corrects single-bit errors Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset	Intel® C612 chipset
SATA	SATA3 (6Gbps) via C612 controller RAID 0, 1, 10 support
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC
Network Controllers	Intel® i350-AM2 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output 1x Realtek RTL8201N PHY (dedicated IPMI)

Memory Type	2133/1866/1600/1333MHz ECC DDR4 SDRAM 72-bit, 288-pin (RDIMM/LRDIMM) / 284-pin gold-plated DIMMs
SATA	10x SATA3 (6Gbps) ports
BIOS Type	8MB SPI Flash EEPROM with AMI BIOS
Motherboard	Super X10SRi-F
Core / Cache	Up to 18 Cores / Up to 45MB Cache

SYS-5018R-M
